| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | DOOR |
| Certification: | CE / IS09001 |
| Model Number: | DR.TD.6629 |
| Minimum Order Quantity: | 1 lane |
| Price: | USD |
| Packaging Details: | plywood case |
| Delivery Time: | 7-10 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 2500lanes/month |
| Box Material: | Brushed Stainless Steel&Alluminum Alloy | Box Thickness: | 2.0mm |
|---|---|---|---|
| Dimension: | 1600*140*1000mm | Working Temperature: | -20℃ ~ 70℃ |
| Working Environment: | Indoor | Swing Arm: | Acrylic |
| IR Sensor: | 14 Pairs | MTBF: | 20 Million Times |
| High Light: | 0.3S Open Speed Gate Turnstile,Alluminum Alloy Speed Gate Turnstile,35person/min Access Control Speed Gates |
||
| Model | DR.TD.6629 |
| Material: | Top cover aluminum alloy,body SUS304 brushed stainless steel,whole body 2.0mm |
| Size | L1600*W140*H1000mm |
| Swing arm | Acrylic (tempered glass available) |
| Passage width | 600-900mm |
| Input power | AC220V,50/60HZ |
| Motor | Servo motor |
| Work temperature | -20℃ ~ 70℃ |
| Rated power | Single core100W,double core 200W |
| Work environment | Indoor |
| Passage speed | 35-40person/min |
| Communication Interface | RS485, open/close signal(relay), dry contact |
| Humidity | ≤90%(no condensation) |
| MTBF | ≧20 million times |
| Anti-pinch | Infrared anti-pinch,current detection anti-pinch,logic anti-pinch |
| Passage direction | Uni-directional/Bi-directional |
| IP level | Ip42 |
| Voltage | AC110V/AC220V±10% 50-60Hz |
Main Features of speed gate turnstile:
Traditional mortise and tenon process design, the appearance of the whole machine has no screws and no keyholes.
Standard 14-pair photocell to protect pedestrian safety.
Servo motor driving with 20 million times MTBF.
Main Functions of speed gate:
1) Rapid identification technique, available to identify accurately and efficiently the magnetic card, bar code card, ID card and IC card.
2) Servo Motor, Maintenance Free
4) Real time trouble self-detect and alarm indication, ensuring system safe operation and facilitating maintenance and operation
5) With direction indication, guiding passenger to entry and exit.
6) Self automatic locking to prevent forcely passing without the card
7) Automatic counting and displaying number of passenger, facilitating observation and with a displaying total amount as high as 90,000
8) Light and sound alarm indication function, preventing illegal entry or irregular passing
9) Powerful on-line intelligent control mode, facilitating you:
A) To adjust the operation speed of the barrier according to the flow of passenger and improve the passing rate.
B) To set up operation mode for passage entry and exit.
C) To read card with multiple times, the special function meeting the application requirements of a particular site.
D) To set up the card reading with or without memory.
E) To select a reasonable normally open or close mode, to divert the flow of passengers effectively.
F) Setting function humanized for reset of over time pa ssing.
10)The infrared sensing technique realizes real time monitor of passage, safe protection and tail-proof.
12) The processing mode in emergency or in special conditions.
13) Having standard input/output port, facilitating the integration of the system and the other equipment, to realize far end control management.
Pedestrian Turnstile gates Applications:
Pedestrian turnstile gates have a wide range of applications. Since pedestrian turnstile gates are used to control people traffic flow, for entrance security, and for identification purposes. The gates can really be used anywhere. These turnstiles are most often used in high-traffic transportation hubs like subway systems, train stations, airports, and bus terminals. Also They are used at high-end buildings, offices, gyms, football stadium, etc. They can even be fitted with card readers for completely autonomous operation, as well as QR code readers, face readers and fingerprint readers. DOOR can provide a wide range of integration with these readers.
