Listed Pedestrian Turnstile and Parking Devices Manufacturer for over 15 Years!
Stock Code:832966
| Place of Origin: | China |
|---|---|
| Brand Name: | DOOR |
| Certification: | CE/IOS |
| Model Number: | DR.MJ.3642-A1 |
| Minimum Order Quantity: | 1PCS |
| Price: | USD |
| Packaging Details: | paper carton package |
| Payment Terms: | T/T |
| Supply Ability: | 2500pcs/month |
| Voltage: | DC12V/2A | Screen: | 8 Inch HD IPS Screen |
|---|---|---|---|
| Dimension: | 242*133*22mm | IP Level: | IP66 |
| MTBF: | >50,000h | Working Temperatureure: | -30℃ - +60℃ |
| Face Capacity: | 24,000 | Card Capacity: | 24,000 |
| Record Capacity: | 90,000 |
Product Features:
* Support dual lenses live body recognition.
* Special face recognition algorithm, recognition accuracy higher than 99.7%, recognition time less than 0.3s.
* Tracing fave moving under strong backlight environment.
* Adopt Linux operating system, stability is better.
* Support TF card storage, picture continuously save for over one year.
* MTBF>50,000h
* Support 100,000+ face comparison database and 90,000 recognition record.
* Rich port protocol, support TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, DNS, DDNS, DHCP, SMTP, UPNP, MQTT ptotocol under multi-platform like Windows / Linux.
* Water-proof, IP66.
* Video partial shield
* Externally connect to access control or Wiegand reader via Wiegand 26/34.
* Device can be managed, looked for and set after local login.
Product Parameter:
| Hardware | ||
| Prosessor | Dual-core ARM Cortex-A7 and RISC-V MCU | |
| Operating system | Linux operating system | |
| Storage | 1GB memory + 8GB eMMC | |
| Camera | Dual lenses, 2.1million effective pixel | |
| Imaging devices | 1/2.8'' Progressive Scan CMOS | |
| Lens | 4.5mm focal distance | |
| WiFi module (Optional) | 2.4GHz WiFi SoC chip, integrate IEEE 802.11b/g/n baseband and RF circuit, max.72.2Mbit/s PHY rate | |
| Card module(Optional) | 13.56MHz, support Mifare S50,S70 card, ultralinght card, NTAG card, DESFire D21, D41, D81, non-touch CPU card | |
| Touch panel (Optional) | Capacitive Multi-touch panel | |
| Loudspeaker | Voice playing contents can be customized | |
| Performance | ||
| Recognition height | 1.2~2.3M, angle adjustable | |
| Recognition distance | 0.5~2.5M | |
| Face reconition angle | left & right 30degree, up & down 30degree | |
| Recognition record capacity | 90,000 | |
| Face capacity | 24,000 | |
| Interface | ||
| Power input | DC12V/2A | |
| Network port | 1 RJ45 10M / 100M adaptive Ethernet port, Gigabit port can be customized | |
| Wiegand port | 1 Wiegand output port, 1 Wiegand input port | |
| Door lock port | 1 door lock output port | |
| Communication port | 1 RS485 communication port | |
| USB port | 1 USB port | |
| Camara parameter | ||
| Camera | Dual camera, full G lenses, support live body inspection | |
| Effective Pixel | 2.1million effective pixel, 1920*1080 | |
| Min. illumination | Colorful 0.01Lux @F1.2(ICR); Black and white 0.001Lux @F1.2 (ICR) | |
| SNR | ≥50db (AGC OFF) | |
| WDR | 120db, ISP algorithm, face partial exposure | |
| Video encoding | H.265 Main profile encoding/H.264 BP/MP/HP encoding/MJPEG encoding | |
| Dual stream resolution rate | Main stream | 50Hz: 25fps (1920x1080, 1280x720) |
| 60Hz: 30fps (1920x1080, 1280x720) | ||
| Sub stream | 720*576, 1-25(30)frame/s 640*480, 1-25(30)frame/s 320*240, 1-25(30)frame/s | |
| Normal parameter | ||
| Working temperature | -30℃～60℃ | |
| Relative humidity | ≤90%, no condensation | |
| Salt spray level | Above Rp6 | |
| Power | 20W(max.) | |
| ESD | Touch ±6KV, air ±8KV | |
| Voltage | DC12V/2A | |
| IP level | IP66 | |
| Screen size | 8'' HD IPS screen, resolution rate 1280*800 | |
| Dimension | 242(L)*133(W)*22(H)mm | |
