5) Input interface: 12V level signal or 12V pulse signal with pulse width> 100ms, driving current> 10mA
6) Communication interface: RS485 electrical standard,
7) Communication distance: ≤1200 meters
8) Maximum channel width: 900mm
9) Gate opening and closing time: 1.5 seconds
10) The whole machine adopts 304 stainless steel, thickness is 1.2mm
11) 5 pairs of infrared
1)Rapid identification technique, available to identify accurately and efficiently the magnetic card, bar code card, ID card and IC card.
2)DC Brushless Motor, Maintenance Free
3)On-line or off –line mode(optional)
4)Real time trouble self-detect and alarm indication, ensuring system safe operation and facilitating maintenance and operation
5)With direction indication, guiding passenger to entry and exit.
6)Self automatic locking to prevent force passing without the card
7)Automatic counting and displaying number of passenger, facilitating observation and with a displaying total amount as high as 90,000
8)Light and sound alarm indication function, preventing illegal entry
