Listed Pedestrian Turnstile and Parking Devices Manufacturer for over 15 Years!
Stock Code:832966
| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | Shenzhen Door |
| Certification: | CE / IS09001 |
| Model Number: | DR.TD.6771-1 |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Wooden packing |
| Delivery Time: | 5-7days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 2500 sets/months |
| Material: | Ss316/sus304 | Size: | 1580*1200*2310mm |
|---|---|---|---|
| Passage Width: | ≤650mm | Passing Speed: | 20-35 Personal/min |
| Working Temperature: | -25℃-+70℃ | Mean Cycles Between Failure: | 5 Million Times |
| IP Rating: | IP65 | Voltage: | AC110V/AC220V±10% 50-60Hz |
| Driving Motor: | DC Brushless Motor | Method Of Position: | Motor Driving |
| High Light: | SS316 Full Height Turnstile,SUS304 Full Height Turnstile,SS316 Automatic Turnstile |
||
Main features:
The surface of the movement unit adopted anti-rust and anti-corrosion treatment, durable. Providing multiple RJ45 interface and RS485/232 interface, can connect a variety of card reader, magnetic stripe, EMID, MIFARE 1 CI, Ti, and support variety data format, WIEGRAND26, WIRGRAND34, WIRGRAND66, also can connect the bar code reader, fingerprint recognizer, palm print recognizer, face recognizer, strong compatibility, convenient for system integration.
| Basic Parameters | ||
| 1 | Input voltage | AC 220V 50HZ |
| 2 | Work voltage | DC 24V /50W |
| 3 | Housing Material | 304 Stainless Steel |
| 4 | Arm rotation angle | 90/120 degree |
| 5 | Lane Width | ≦650mm |
| 6 | Opening response time | ≦0.2s |
Packing:
Project installation pictures:
Any further questions please do not hesitate to contact us.
