DC24V Ultra-Safe | 30W Energy Star | 550mm High-Flow Passage

Basic Information

Place of Origin:	China
Brand Name:	DOOR or OEM
Certification:	CE / IS09001
Model Number:	WD.TD.6380X-EN

Minimum Order Quantity:	1 Unit
Price:	Negotiable
Packaging Details:	wood carton
Delivery Time:	5-7 working days
Payment Terms:	T/T
Supply Ability:	2500 sets per month

Get Best Price Contact Now

Material:	304 Stainless Steel	Turnstile Material:	SUS304 Stainless
Communication Interface:	RS232	Swing Arm Available:	Acrylics Or Tempered Glass
Opening Signal Input::	Dry Contact	Working Environment:	-15℃-60℃
Pass Speed:	20 Personal/min	Support System:	Face Recognition,ic/id Card,fingerprint
Passage Width:	600mm (MAX)	IP Rating:	IP55
Mean Cycles Between Failure:	20 Million Times	Voltage:	AC110V/AC220V±10% 50-60Hz
Method Of Position:	Motor Driving	Mtbf:	5 Million Times
Size:	1200x280x1000m	Access Means::	IC Card; Face Recognition
Highlight:	304 stainless steel tripod turnstile gate , face recognition turnstile gate , stainless steel turnstile with warranty

DC24V Ultra-Safe | 30W Energy Star | 550mm High-Flow Passage

Product Specifications

▍Structural Integrity

Armor-Graded SUS304 | Brushed Finish Anti-Vandalism
Reinforced Body : 2.0mm Top Cover + 1.5mm Full-Wrap Steel Shell
Heavy-Duty Tripod Arm : Ø32mm Stainless Steel Tube
Dimensions : 420(L)×330(W)×980(H)mm (Compact Footprint)

▍Performance Engineering

HyperFlow Passage :550mm Clear Width | 20+ Persons/Min (30% Faster Than Industry Avg.)
Lightning Access : 1s Opening Response | 5ms Motor Activation
Extreme Environment Ready : -20℃~60℃ Operation | IP55 Shield (Dust/Jet Water Resistant)
Military Durability : 5 Million MCBF | 20-Year Corrosion Resistance

Key Features

Seamless Third-Party Integration: Compatible with industry-standard access control devices (IC/ID card readers, QR code scanners, facial recognition terminals, etc.).
Emergency Safety: Dedicated fire button interfaces with the system for automatic gate release during emergencies.
High-Speed Detection: 8 military-grade infrared sensors with advanced algorithms prevent tailgating, reverse passage, and clamping.
Enhanced Safety: Multi-layer anti-pinch design and optional widened lane for luggage/wheelchair access.
Seamless Integration: Compatible with RS485, TCP/IP (optional), and dry contact interfaces, works with all major access control systems.

(Note: Recognition systems not included; product provides standardized connection interfaces only)

Applications

Widely used for official or corporate buildings, sectioning off certain areas in University lab access points, industrial buildings or hospital radiology departments.

DC24V Ultra-Safe | 30W Energy Star | 550mm High-Flow Passage 0

Customization Options

Customized logo (Min. order: 2 pieces)
Customized packaging (Min. order: 2 pieces)
Graphic customization (Min. order: 2 pieces)

Supplier's Customization Ability

Minor customization
Drawing-based customization
Sample-based customization
Full customization

Shipping Information

Shipping fee and delivery date to be negotiated. Contact supplier for more details.
