Place of Origin: | China |
---|---|
Brand Name: | DOOR or OEM |
Certification: | CE / IS09001 |
Model Number: | DR.TD6632 |
Minimum Order Quantity: | 2 sets |
Price: | Negotiable |
Packaging Details: | wood carton |
Delivery Time: | 5-7 working days |
Payment Terms: | T/T |
Supply Ability: | 2500 sets per month |
Material: | 304# Stainless Steel | Suitable For: | Access Control, Entrance And Exit Control |
---|---|---|---|
Turnstile Material: | SUS304 Stainless | Communication Interface: | RS485 |
Power Supply: | AC110/AC220+/-10% | Swing Arm Available: | Acrylics Or Tempered Glass |
Driving Motor: | Servo Motor | Opening Signal Input:: | Dry Contact |
Working Environment: | -25℃-+70℃ | Pass Speed: | 30-35 Personal/min |
Support System: | Face Recognition,ic/id Card,fingerprint | Motor: | DC24V Brushless Motor |
Passage Width: | ≤700 Mm | IP Rating: | IP42 |
Mean Cycles Between Failure: | 20 Million Times | Voltage: | AC110V/AC220V±10% 50-60Hz |
Method Of Position: | Motor Driving | Mtbf: | 5 Million Times |
Size: | L2613 .92*W1100*H1555.5mm | Number Of Sensor: | 34 Groups |
Highlight: | stainless steel airport turnstile,airport turnstile with face recognition,fingerprint airport turnstile |
Attribute | Value |
---|---|
Material | 304# Stainless Steel |
Suitable For | Access Control, Entrance And Exit Control |
Turnstile Material | SUS304 Stainless |
Communication Interface | RS485 |
Power Supply | AC110/AC220+/-10% |
Swing arm available | Acrylics Or Tempered Glass |
Driving Motor | Servo motor |
Opening Signal Input | Dry Contact |
Working environment | -25℃-+70℃ |
Pass speed | 30-35 Personal/min |
Support System | Face Recognition, IC/ID Card, Fingerprint |
Motor | DC24V Brushless Motor |
Passage Width | ≤700 mm |
IP Rating | IP42 |
Mean Cycles Between Failure | 20 million times |
Voltage | AC110V/AC220V±10% 50-60Hz |
Method of position | Motor Driving |
MTBF | 5 Million Times |
Size | L2613.92*W1100*H1555.5mm |
Number of Sensor | 34 groups |
Widely used for official or corporate buildings, university lab access points, industrial buildings, and hospital radiology departments.
Shipping fee and delivery date to be negotiated. Contact supplier for more details.
